Brand:Honeywell
Model:HUS-D4-PRO
HUS-D4-PRO Honeywell decoder
Functional features
Low support hd video (1080 p, 720 p), millions of pixels, standard resolution video decoding
Provides four HDMI port, each port can solve 2 road 1080 p or 720 p or 9 road 4 D1 resolution video
Low each port support separately display and image segmentation, a single device can display the most 36 images (D1)
Low support for different types of coding: h. 264, MPEG4, MPEG2, MJPEG
Support the TV wall in the flexible configuration, set up IP digital surveillance system together
Provide digital matrix solution, build cost-effective IP monitoring center
specification
Processing unit (CPU), Intel quad-core processors, 3.3 GHz
4 GB of memory
Network 1 GBPS (one billion Ethernet, RJ45)
Digital video HD webcam (HD)
Mega pixel cameras (Mega - pixel)
Standard resolution network Camera (IP Camera)
The network video server DVR
Format video coding h. 264, MPEG4, MPEG2, MJPEG
The output shows
Image segmentation full-screen single image display
2 x2, 3 x3, 4 x4, 4,6,8,9,13,16 split-screen display
Provide surround video real-time display (12 surrounding the main view and auxiliary image)
Resolution 1080 p, 720 p, Megapixel, D1
Video output 4 road digital video signal output (HDMI V1.4)
Size (W * H * D) 427 mm * 177 mm * 450 mm (4 u) (rack installation)
The weight of 14 kg
The power supply requirements
The power of 100 ~ 240 vac, 50/60 hz
Power 450 w
Environmental parameters
Working temperature of 10 ℃ ~ 35 ℃
Storage temperature - 40 ℃ ~ 65 ℃
Relative humidity of 10% ~ 85%, and the condensation
